| Lifting capacity(T) | 5 | 10 | |
| Span(m) | 35 | 35 | |
| Lifting height(m) | 10 | 10 | |
| Lifting speed(m/min) | Lifting | 37.08 | 40.92 |
| Cross travel | 49.4 | 49.6 | |
| Long travel | 34.5 | 30.5 | |
| Weight(T) | Trolley | 13.8 | 17.7 |
| crane | 126.3 | 137.5 | |
| Wheel pressure (Kn) | 22.9 | 26.6 | |
| Grab | distance to cabin(mm) | 1181 | 1104 |
| length after opening(mm) | 3000 | 3700 | |
| width(mm) | 1852 | 2256 | |
| volume(M3) | 3 | 4 | |
| density of material(t/m3) | 0.8-1.0 | 0.8-1.0 | |
| Recommended rail | 43kg/m | 43kg/m | |
