| Lifting capacity | t | ‘5/5 | 10/10 | 16/16 | |||
| Span | m | 31.5 | 31.5 | 31.5 | |||
| Working class | A6 | ||||||
| Max Lifting height | m | 20/22 | 22 | 22 | |||
| Speed | lifting | m/min | 40.1/15.6 | 40/10.4 | 41.8/13 | ||
| Cross travel | 44.6 | 45.6 | 43.2 | ||||
| long travel | 86.4 | 89 | 75.3 | ||||
| Weight | trolley | Kg | 7600 | 11500 | 19900 | ||
| total weight | indoor | 43800 | 50400 | 72000 | |||
| out door | 44700 | 51200 | 73500 | ||||
| Max wheel pressure | indoor | kn | 168 | 229 | 321 | ||
| out door | 171 | 233 | 324 | ||||
| Grab | Model | 113 | 110 | 106 | 102 | 130 | 148 |
| Type | light | medium | heavy | super heavy | super heavy | heavy | |
| Volume(M3) | 2.5 | 1.5 | 1 | 0.75 | 2.5 | 4 | |
| Density t/m3 | 1-1.7 | 1.7-2.5 | 2.5-3.3 | 2.5-3.3 | |||
| Dead weight(kg) | 2632 | 2615 | 2568 | 2546 | 8305 | 10123 | |
| Recommended rail | 43kg/m | QU70 | |||||
| Power source | 380-600V 50HZ 3 Phase | ||||||
