| Lifting weight | T | 3 | 5 | 10 | 16 | 20 | ||
| Operation mode | Pedant/ cabin | |||||||
| Speed | hoisting | m/min | 0.8/8 | 0.8/8 | 0.7/7 | 0.35/3.5 | 0.6/6 | |
| cross travel | 20 | 20 | 20 | 20 | 20 | |||
| long travel | ground | 20/30 | 20/30 | 20/30 | 20/30 | 20 | ||
| cabin | 20/30 | 20/30 | 20/30 | 20/30 | 20 | |||
| Motor | lifting | Type/kw | ZD1 32-4/4.5 | ZD1 41-4/7.5 | ZD1 51-4/13 | ZD1 51-4/13 | ZD1 52-4 | |
| cross travel | YSE80 -0.4*2 | YSE80-0.8*2 | YSE80-0.8*2 | YSE90L-1.5*2 | YSE90L-1.5*2 | |||
| long travel | ground | YSEP90L-1.5*2 | YSE90L-1.5*2 | YSE90L-1.5*2 | YSEP90L-1.5*4 | YSEP90L-1.5*4 | ||
| cabin | ZDR100-1.5*2 | ZDRI00-1.5*2 | ZDRI00-1.5*2 | ZDR100-1.5*4 | ZDR100-1.5*4 | |||
| Lifting height | m | 9 12 | 12 18 | 9 12 | 9 12 | 9 12 | ||
| Span | m | 31.5 | 31.5 | 31.5 | 31.5 | 31.5 | ||
| Working class | A3-A4 | |||||||
| Recommended rail | kg/m | 24 | 38 | 38 | 38 | 38 | ||
| Max wheel pressure | kn | 87 | 95 | 132 | 178 | 218 | ||
| Dead weight | pendant | T | 19.1 | 20.7 | 23 | 26.7 | 29.7 | |
| cabin | 19.9 | 21.5 | 23.8 | 27.5 | 30.5 | |||
